Usable area: 79.66 m2 / The cost of the realization: 71 000 EUR
Show mirror image
Price: 830 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Detailed drawings
List of materials
Comments (3)
Cypisek 2 is enlarged version of the Cypisek house. This is a one-story house for a family of 4, covered by a simple gable roof, with a non-usable attic, which can be adapted to the usable attic. The front elevation of house was diversified by a corner arcade entrance and a covered bay window of kitchen. The elevation of the garden is enriched by a wide exit doors from the living room to the terrace, and an arcade on the part of the terrace. The whole shape of the building is simple but curiously composed. Traditional roofs are connected together with modern detail and materials. The interior of the ground floor was divided into day and night part - with three bedrooms and a bathroom. In the living room a corner fireplace and a convenient kitchen with dining table in the bay window was planned. Stairs from the hall lead to the attic, which can easily be adapted to usable attic. There is also a mirror version of the Cypisek 2.
Specifications:
- Cubature: 544 m3/ 19208,64 ft3
- Built-up area: 104,71 m2/ 1126,68 ft2
- Total area: 104,71 m2/ 1126,68 ft2
- Net area: 81,75 m2/ 879,63 ft2
- Usable area: 79,66 m2/ 857,14 ft2
- Roof area: 157,22 m2/ 1691,69 ft2
- Roof slope: 30 degrees
- Height of the building: 6,14 m (6,39 m with foundation)/ 20,14 ft (20,96 ft with foundation)
- Wide of the building: 12,37 m / 40,57 ft
- Length of the building: 9,83 m / 32,24 ft
- Minimum plot width: 20,37 m / 66,81 ft
- Minimum plot length: 17,83 m / 58,48 ft
- Height of rooms: 2,7 m / 8,86 ft
Materials:
• Foundations - Concrete benches and foundation walls of concrete blocks
• External walls - brick walls - porotherm 25 blocks + polystyrene + thin-layer plaster
• Ceiling - Teriva
• Elevation - thin-layer plaster on polystyrene
• Roof - tile
The costs of implementing:
| The raw state open | 29 100,00 EUR |
| The raw state closed | 40 500,00 EUR |
| The cost of finishing works | 30 600,00 EUR |
| Execution of turnkey home | 71 000,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Cypisek 2 - detailed file
House plan Cypisek 2 - detailed file - mirror
