Practical B house plan

Usable area: 113.16 m2   /   The cost of the realization: 97 300 EUR
House plan Practical B - front visualization
Show mirror image


Practical B house plan is a small family house for a family of four. This is a storey building with an attic. The same house plan we presented in two variants - as a family house for one family and the house divided into two premises - with two separate apartments on the ground floor and in the attic. This version of the house is the house divided into two premises – it is a great solution especially for families living together, for example, three-generation. Bottom flat may be occupy by the main family, on top of the house may live adult children with his/her family. Practical B house plan is simple in construction, and is not have complicated structure – thanks to this implementation costs will be reasonable. Common part of both apartments is a common entrance, boiler room and staircase with the hall. Apartment on the ground floor - two rooms apartment with kitchen and bathroom. In the attic you will find four-rooms (or three-room with separate kitchen). The building may be interesting for multigenerational families, it can also be a great idea for a holiday house - where at once, independently of each other can stay two families.

Specifications:
  • Cubature: 412 m3 / 14547,72 ft3
  • Built-up area: 81,6 m2 / 878,02 ft2
  • Total area: 147,12 m2 / 1583,01 ft2
  • Net area: 121,05 m2 / 1302,50 ft2
  • Usable area: 113,16 m2 / 1217,60 ft2
  • Roof area: 143,55 m2 / 1544,60 ft2
  • Roof slope: 38 degrees
  • Height of the building: 7,65 m (7,95 m with foundation) / 25,09 ft (26,08 ft with foundation)
  • Wide of the building: 8 m / 26,24 ft
  • Length of the building: 12,2 m / 40,02 ft
  • Minimum plot width: 16 m / 52,48 ft
  • Minimum plot lengthi: 19,56 m / 64,16 ft
  • Height of rooms: 2,60 m / 8,53 ft
Materials:
  • Foundations – poured concrete
  • External walls – wooden skeleton 14x4 + OSB + mineral wool insulation 10 cm + thin layer plaster
  • Ceiling -  wooden beams
  • Roof -  tile or meatal roofing tile
  • Elevation - thin-layer plaster






The costs of implementing:
The raw state open 24 400,00 EUR
The raw state closed 38 100,00 EUR
The cost of finishing works 59 200,00 EUR
Execution of turnkey home 97 300,00 EUR

Net notified costs, do not include VAT



To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.



House plan Practical B - detailed file

House plan Practical B - detailed file - mirror

Comment
Practical B house plan 2183 Gregores
2012.03.19 0 Pozytywny komentarz Negatywny komentarz

Hi all, I see that this hause plan is very popular, I also chose this one and I do not regret the cottage is very cool and functional. Regards.

Practical B house plan 626 Houk
2012.02.10 0 Pozytywny komentarz Negatywny komentarz

Hello I have a question, if anyone already put raw state of this house? I would like to assess the size of the house in live before buying the same.

Practical B house plan 627 Praktyczna_Kasia
2012.02.10 0 Pozytywny komentarz Negatywny komentarz

In the end I found my dream house plan.
