Practical A house plan

Usable area: 113.16 m² / The cost of the realization: 98 700 EUR

House plan Practical A - front visualization

Show mirror image

Price: 900 EUR

Description Plans Elevations Situations Animation Variants (0) Detailed drawings List of materials Comments (3)

Practical A house plan is a small family house for a family of four. This is a storey building with an attic. The same house plan we presented in two variants - as a family house for one family, and the house divided into two premises - with two separate apartments on the ground floor and in the attic. This version of the house is a family building. Shape of the building is very simple, certainly will not be difficult to build. Well-balanced proportions of the house and architectural details make the external appearance of the building is very attractive. Inside on the ground floor is designed living room combined with spatially hall, stairs, kitchen, utility room and an extra room - study or a guest bedroom. On the first floor there are three bedrooms, including one as parents’ apartment with bathroom and dressing room, and garden terrace. Practic house plan, despite the small space has a lot of rooms and functional solutions seen in large houses. The strength of this house is its simplicity and clear up functional layout.

Specifications:

Cubature: 412 m3 / 14547,72 ft3
Built-up area: 81,6 m2 / 878,02 ft2
Total area: 147,12 m2 / 1583,01 ft2
Net area: 121,05 m2 / 1302,50 ft2
Usable area: 113,16 m2 / 1217,60 ft2
Roof area: 143,55 m2 / 1544,60 ft2
Roof slope: 38 degrees
Height of the building: 7,65 m (7,95 m with foundation) / 25,09 ft (26,08 ft with foundation)
Wide of the building: 8 m / 26,24 ft
Length of the building: 12,2 m / 40,02 ft
Minimum plot width: 16 m / 52,48 ft
Minimum plot lengthi: 19,56 m / 64,16 ft
Height of rooms: 2,60 m / 8,53 ft

Materials:

Foundations – poured concrete
External walls – wooden skeleton 14x4 + OSB + mineral wool insulation 10 cm + thin layer plaster
Ceiling - wooden beams
Roof - tile or meatal roofing tile
Elevation - thin-layer plaster

The costs of implementing:

The raw state open	24 900,00 EUR
The raw state closed	37 900,00 EUR
The cost of finishing works	60 900,00 EUR
Execution of turnkey home	98 700,00 EUR

Net notified costs, do not include VAT

Order

Additions to the project:

Energy-saving package free

Ventilation and fireplace package 90,00 EUR

Central vacuum package 70,00 EUR

The electronic version of the project 120,00 EUR

Solar installation package 70,00 EUR

Underfloor heating package 80,00 EUR

Heat pump package 70,00 EUR

Water jacket package 70,00 EUR

Boiler for solid fuel package 80,00 EUR

Air conditioning package 80,00 EUR

Fencing projects 140,00 EUR

Septic tanks sealed package free

House plan Practica l- bills of materials

To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.

House plan Practical A - detailed file - mirror

House plan Practical A - detailed file
