Usable area: 83.86 m2 / The cost of the realization: 64 400 EUR
Show mirror image
Price: 830 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Realizations (11) Detailed drawings
List of materials
Comments (3)
Booby house plan is a one-storey house from wooden bales, which could serve as a year-round home for a family of 4 - 5 people as well as a summer house. The construction of the house was on the inside insulated with mineral wool, so the building meets all the heat standards. The house itself, besides to a living room with fireplace and three bedrooms with bathroom has a large covered terrace, which can be partly glazed. In the utility room heating boiler was designed. Dudek house plan is also available in a mirror version.
Specifications:
- Cubature: 258 m3/ 9109,98 ft3
- Built-up area: 98,21 m2/ 1059,74 ft2
- Total area: 98,21 m2/ 1059,74ft2
- Net area: 87,56 m2/ 942,15 ft2
- Usable area: 83,86 m2/ 902,33 ft2
- Roof area: 180 m2/ 1936,80 ft2
- Roof slope: 24 degrees
- Height of the building: 5,08 m (5,40 m with foundation)/ 16,66 ft (17,71 ft with foundation)
- Wide of the building: 12,12 m / 39,75 ft
- Length of the building: 8,23 (13,02) m / 26,99 (42,70) ft
- Minimum plot width: 20,12 m / 65,99 ft
- Minimum plot length: 19,02 m / 62,39 ft
- Height of rooms: 2,6 m / 8,53 ft
Materials:
• Foundations - concrete benches, walls of concrete blocks
• External walls - solid log walls, insulated from the inside, post-and-plank
• Ceiling - wooden truss girders
• Elevation – solid logs
• Roof - tile
The costs of implementing:
| The raw state open | 26 400,00 EUR |
| The raw state closed | 36 700,00 EUR |
| The cost of finishing works | 27 700,00 EUR |
| Execution of turnkey home | 64 400,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Dudek- detailed file - mirror
House plan Dudek- detailed file - mirror
