Usable area: 141.71 m2 / The cost of the realization: 135 000 EUR
Show mirror image
Price: 1000 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Realizations (1) Detailed drawings
List of materials
Comments (3)
Prank 2 house plan is a variant version of Prank house plan. This time the villa was designed with a garage. This house is intended for the family of 4-5 people. This is a one-storey house with an attic designed on a rectangular plan, with adjoined garage. The house is covered by a hipped roof, with additional dormers and additional roof over the garage. External appearance of house refers to the pre-war residence built in the cities-gardens or in the suburban summer resorts. Uniting the historical detail of the facades with modern materials and building solutions obtained very nice style. Entrance porch with buttresses columns, buttresses at the corners and strip foundations, balcony in the garden elevation on the buttresses columns - all these elements heighten the effect of a home stable in the surrounding area. In this way the building looks very stately. Interior of house is divided into a living area on the ground floor and bedrooms on the top floor. On the ground floor there are: living room with dining area with a beautiful bay window, centrally set fireplace, hall - with a nice two-speed stairs, partially open kitchen, and an additional room that could be used as a study or bedroom. Additionally next to the porch there are: spacious utility room - boiler room, wc with shower, and a garage. On the top floor there are three bedrooms with one large shared bathroom and an additional dressing room. On the mezzanine floor above the garage the attic is designed that can be easily adapted for extra room or sports room. There is a mirror version of this house plan.
Specifications:
- Cubature: 801 m3 / 28283,31
- Built-up area: 140,29 m2 / 1509,52 ft2
- Total area 229,37 m2 / 2468,02 ft2
- Net area: 152,64 m2 + garage+ attic / 1642,41 ft2 + garage+ attic
- Usable area: 141,71 m2 / 1524,80 ft2
- Roof are: 228,75 m2 / 2461,35 ft2
- Roof slope: 38 degrees
- Height of the building: 8,14 m (8,44 m with fundation) / 26,70 ft (27,68 ft with fundation)
- Szerokość budynku: 14,3 m / 46,90 ft
- Długość budynku: 11,36 m / 37,26 ft
- Min szerokość działki: 21,52 m / 70,59 ft
- Min długość działki: 20,66 m / 67,76 ft
- Wysokość pomieszczeń: 2,7 m / 8,87 ft
Materials:
• Foundations: concrete benches and foundation walls with concrete blocks
• External walls: brick walls - airbrick porotherm 25 + polystyrene + thin-layer plaster
• Ceiling: Teriva
• Elevations: thin-layer plaster on polystyrene
• Roof: tile
The costs of implementing:
| The raw state open | 48 100,00 EUR |
| The raw state closed | 71 400,00 EUR |
| The cost of finishing works | 63 700,00 EUR |
| Execution of turnkey home | 135 000,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Prank 2 - detailed file - mirror
House plan Prank 2 - detailed file
