Usable area: 83.13 m2 / The cost of the realization: 69 300 EUR
Show mirror image
Price: 870 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Detailed drawings
List of materials
Comments (3)
Flea house plan is one of the newer house plans. This house is designed for four to five people. It can be used as single-family house all year round or as a holiday house. The simple shape of the building is designed on a square plan and covered with a gable roof. The facades were decorated with pretty eaves, small roofs entrance and garden. The project has a diverse facade - designed as plastered floor, attic - clad by wood cladding. House is very neat, has a well-balanced proportions and scale. Due to the clear layout design house construction should be easy and inexpensive. Inside the house, on the ground floor was planned living-dining room with kitchen, utility room, bathroom and room - master bedroom. In the attic was planned two children bedrooms and a bathroom. Flea is designed to be able to finish the attic in the second stage. There is also available a mirror version of this house plan.
Specifications:
- Cubature: 294 m3 / 10381,14 ft3
- Built-up area: 77,09 m2 / 829,49 ft2
- Total area: 111,14 m2 / 1195,87 ft2
- Net area: 88,54 m2 / 952,69 ft2
- Usable area: 83,13 m2 / 894,48 ft2
- Roof area: 135,64 m2 / 1459,49 ft2
- Roof slope: 30 degrees
- Height of the building: 6,30 m (6,60 m with foundation) / 20,66 ft (21,65 ft with foundation)
- Wide of the building: 8,78 m / 28,80 ft
- Length of the building: 8,78 m / 28,80 ft
- Minimum plot width: 16,78 m / 55,04 ft
- Minimum plot length: 17,76 m / 58,25 ft
- Height of rooms: 2,65 m / 8,69 ft
Materials:
- Foundations – poured concrete
- External walls - bilayer wall aerated concrete 24 + polystyrene 15 (or mineral wool)
- Ceiling - reinforced concrete TERIVA
- Roof - tile or meatal roofing tile
- Elevation - thin-layer plaster
The costs of implementing:
| The raw state open | 25 900,00 EUR |
| The raw state closed | 35 900,00 EUR |
| The cost of finishing works | 33 400,00 EUR |
| Execution of turnkey home | 69 300,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Pchelka - detailed file
House plan Pchelka - detailed file - mirror
