Pine 5 house plan

Usable area: 78.03 m² / The cost of the realization: 67 600 EUR

Show mirror image

Price: 870 EUR

Description Plans Elevations Situations Animation Interiors Variants (0) Detailed drawings List of materials Comments (3)

Pine 5 house plan is the next edition of the popular series of Pines houses. House is designed for a family of 3 to 4 people to use as a year-round family house. The building can be used as holiday house. Given the resulting surface this house plan is simple and inexpensive in realization. Solid of the house consists of a substantial part of the attic, covered by a symmetrical gable roof, and two outhouses. Front - comprised room on the ground floor and entrance porch and rear with a large covered terrace. Covered terrace is a great solution magnifying optically a living room. Roof of the building is decorated with two small dormer windows - one on each slope. Inside, on the ground floor is a spacious living room with exposed staircase and a fireplace, kitchen, bathroom, extra room - for example, for a guest bedroom, hall and a boiler room. On the attic is scheduled two bedrooms and a toilet. In house there is designed a central heating form furnace in the boiler room. We have a mirror version of this house.

Specifications:

Cubature: 369 m³ / 13029,39 ft³
Built-up area: 73,51 m²(107,04 m2 - with arcades) / 790,97 ft² (1151,75 ft² - with arcades)
Total area: 106,28 m² / 1143,57 ft²
Net area: 83,22 m² / 895,45 ft²
Usable area: 78,03 m² / 839,60 ft²
Roof area: 171,2 m² / 1842,11 ft²
Roof slope: 45 and 25 degrees
Height of the building: 6,93 m (7,23 m with foundation) / 22,73 ft (23,71 ft with foundation)
Wide of the building: 9,34 m / 30,63 ft
Length of the building: 11,33 m / 37,16 ft
Minimum plot width: 17,34 m / 56,88 ft
Minimum plot length: 18,33 m / 60,12 ft
Height of rooms 2,6 i 2,5 m / 8,53 and 8,2 ft

Materials:

Foundations - concrete bench and foundation walls with concrete blocks
External walls - aerated concrete 24 cm + polystyrene + thin-layer plaster
Ceiling - Teriva
Elevation - thin-layer plaster on polystyrene
Roof - tile

The costs of implementing:

The raw state open	27 700,00 EUR
The raw state closed	38 500,00 EUR
The cost of finishing works	29 100,00 EUR
Execution of turnkey home	67 600,00 EUR

Net notified costs, do not include VAT

Order

Additions to the project:

Energy-saving package free

Ventilation and fireplace package 90,00 EUR

Central vacuum package 70,00 EUR

The electronic version of the project 120,00 EUR

Solar installation package 70,00 EUR

Underfloor heating package 80,00 EUR

Heat pump package 70,00 EUR

Water jacket package 70,00 EUR

Boiler for solid fuel package 80,00 EUR

Air conditioning package 80,00 EUR

Fencing projects 140,00 EUR

Septic tanks sealed package free

Projekt domu Sosenka 5 - zestawienie materiałowe

To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.

House plan Pine 5 - detailed file

House plan Pine 5 - detailed file - mirror
