Usable area: 60.47 m2 / The cost of the realization: 51 900 EUR
Show mirror image
Price: 830 EUR
Description
Plans
Elevations
Situations
Animation Interiors Variants (0)
Realizations (17) Detailed drawings
List of materials
Comments (3)
Pine 2 house plan is recommended as a summer "residence". The house is a variant version of the Pine house plan. Thanks to the large covered terrace where you can relax in the summer evenings the interior of house seems to be bigger. The building can be a holiday or year-round house. We have many variant versions of Pine 2 house plan among other: with terrace covered to the side, with a garage or with a carport. Pine 2 house plan is also available in the version without a covered terrace and in the mirror version.
Specifications:
- Cubature: 216 m3 / 7626,96 ft3
- Built-up area: 79,70 m2 (with terrace) / 857,57 ft2 (with terrace)
- Total area: 76,91 m2 / 827,55 ft2
- Net area: 60,47 m2 / 650,66 ft2
-
Usable area:
- 60,47 m2 wg PN-70/B-02365 / 650,66 ft2 wg PN-70/B-02365
- 60,47 m2 wg PN-ISO 9836:1997 / 650,66 ft2 wg PN-ISO 9836:1997
- Roof area: 130,6 m2 / 1405,26 ft2
- Roof slope: 45 and 16.5 degrees
- Height of the building: 6,56 m (7,06 m with foundation) / 21,52 ft (23,15 ft with foundation)
- Wide of the building: 8,84 m / 28,99 ft
- Length of the building: 5,65 m / 18,53 ft
- Minimum plot width: 16,84 m / 55,24 ft
- Minimum plot length: 15,55 m / 51,00 ft
- Height of rooms: 2,54 m / 8,33 ft
Materials:
- Foundations – monolithic concrete
- External walls – brick walls - aerated concrete + polystyrene
- Interior walls - aerated concrete
- Ceiling - wooden
- Elevation - thin-layer plaster
- Roof - tile or meatal roofing tile
The costs of implementing:
| The raw state open | 12 100,00 EUR |
| The raw state closed | 19 800,00 EUR |
| The cost of finishing works | 32 200,00 EUR |
| Execution of turnkey home | 51 900,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Pine 2 - detailed file
House plan Pine 2 - detailed file - mirror
