Mikrus house plan

Usable area: 61.69 m2   /   The cost of the realization: 63 400 EUR
House plan Mikrus - front visualization
Show mirror image


Mikrus is a nice, little detached house for a family of three to four people. Mikrus is small but roomy and functional at the same time. In a small cubic capacity we have managed to fit a fully-fledged four-room apartment. The house is year-round, it can also be used as summer house. This house has a very simple form. It is built on a square plan with a side of 7.3 meters, covered by a symmetrical gable roof. The building has a simple design, is easy and inexpensive to build, and at the same time - thanks to a good insulation - energy-saving and cheap in later maintaining. Exterior appearance of house combines the traditional form, with modern touches. It's a simple, economical in expression architecture that well fit in any environment. The interior of the house is divided into a living area on the ground floor and bedrooms in the attic. On the ground floor nice living room connects to the kitchen creating one open space. In the living room is a place for fireplace, TV wall, and the area with a dining table. Next to the atrium is designed bathroom and boiler room. The boiler room is a gas, but you can also apply a solid fuel boiler. Cleverly placed stairs do not take up much space and are the decoration of the living room. From the living room by wide patio doors we can go out to the partially covered terrace and garden. In the attic has managed to fit three small bedrooms and a bathroom. Attic can be divided in any other way - at the discretion of Investor - for example, into two larger bedrooms. Mikrus is inexpensive, easy to build and cheap to later maintain. It has everything you would expect from economical house plan. We have a mirror version of this house plan.

Specifications:
  • Cubature: 301 m3 / 10628,31 ft2
  • Built-up area: 53,00 m2 (with arcades: 60,34 m2) / 570,28 ft2 (with arcades: 649,26 ft2)
  • Total area: 84,29 m2 / 906,96 ft2
  • Net area: 66,40 m2 / 714,46 ft2
  • Usable area:
    • 61,69 m2 wg PN-70/B-02365 / 663,78 ft2 wg PN-70/B-02365
    • 66,40 m2 wg PN-ISO 9836:1997 / 714,46 ft2 wg PN-ISO 9836:1997
  • Roof area: 104,98 m2 / 1129,58 ft2
  • Roof slope: 42 degrees
  • Height of the building: 7,43 m (7,63 m with foundation) / 24,37 ft (25,03 ft with foundation)
  • Wide of the building: 7,28 m / 23,88 ft
  • Length of the building: 7,28 m / 23,88 ft
  • Minimum plot width: 15,28 m / 50,12 ft
  • Minimum plot length: 15,28 m / 50,12 ft
  • Height of rooms: 2,55 m / 8,36 ft
Materials:
  • Foundations - concrete bench and foundation walls with concrete blocks
  • External walls - aerated concrete 24 cm + polystyrene + thin-layer plaster
  • Ceiling -  Teriva
  • Roof - ceramic tile
  • Elevation - thin-layer plaster on polystyrene






The costs of implementing:
The raw state open 20 600,00 EUR
The raw state closed 31 200,00 EUR
The cost of finishing works 32 300,00 EUR
Execution of turnkey home 63 400,00 EUR

Net notified costs, do not include VAT



To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.



House plan Mikrus - detailed file

House plan Mikrus - detailed file - mirror
