Usable area: 243.54 m2 / The cost of the realization: 209 300 EUR
Show mirror image
Price: 1110 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Detailed drawings
List of materials
Comments (3)
House with columns is a building created on the basis Benedict house. Stately storey house with attic, hipped roofs and wide dormers. The garage part built another to the main body of the building has been designed at an angle so as to create the impression of the front yard of the entrance to the house and garage entrance directed to one central point. At house with columns, besides the flat for the family of 4 – 5 people an extra room with a kitchenette and a bathroom for an elderly person was designed. The house, therefore, may serve as the headquarters of three generations of the family. On the ground floor is planned large living room with dining area and lobby, and a partially open kitchen. From the living room you can enjoy the garden through two large bay windows. You can also go out to the terrace and an arcade. On the ground floor an additional study near the entrance is planned. The utility rooms was placed in a part of the garage. On the attic there are three bedrooms and two bathrooms. One bedroom is a separate parents’ suite with dressing room and bathroom. Additionally, in the House of columns there is a laundry and drying room (which might also be an additional room), and the attic above the garage, which can be a sports room or for example home cinema.
Specifications:
- Cubature: 1140 m3/ 40253,4 ft3
- Built-up area: 232,39 m2/ 2500,52 ft2
- Total area: 378,29 m2/ 4070,40 ft2
- Net area: 259,3 m2 + garage + attic/ 2790,07 ft2 + garage + attic
- Usable area: 243,54 m2/ 2620,49 ft2
- Roof area: 353 m2/ 3798,28 ft2
- Roof slope: 36 and 38 degrees
- Height of the building: 8,60 m (9,00 m with foundation)/ 28,21 ft (29,52 ft with foundation)
- Wide of the building: 22,97 m / 73,34 ft
- Length of the building: 14,32 m / 46,97 ft
- Minimum plot width: 29,97 m / 98,30 ft
- Minimum plot length: 22,32 m / 73,21 ft
- Height of rooms: 2,90 m / 9,51 ft
Materials:
• Foundations - poured out concrete
• External walls - aerated concrete 24 + 15 polystyrene (or wool)
• Ceiling - reinforced concrete TERIVA
• Elevation - thin-layer plaster
• Roof - ceramic tile or metal roofing tile
The costs of implementing:
| The raw state open | 65 500,00 EUR |
| The raw state closed | 97 500,00 EUR |
| The cost of finishing works | 111 900,00 EUR |
| Execution of turnkey home | 209 300,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House with columns - detailed file
House with columns - detailed file - mirror
