Usable area: 107.45 m2 / The cost of the realization: 95 700 EUR
Show mirror image
Price: 900 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Realizations (8) Detailed drawings
List of materials
Comments (3)
Dominik 2 house plan is a variant version of Dominik house, with an additional garage and a utility room. This is ideal house for a family of 4 - 5 people. Besides to the three bedrooms on the ground floor there are two additional rooms in the attic. The attic can be adapted in the second stage, after residing on the ground floor. Utility room next to the entrance serves as a boiler room - or you can move the stove into the room behind the garage. There is also a mirror version of this house plan.
Specifications:
- Cubature: 482 m3/ 17019,42 ft3
- Built-up area: 138,75 m2/ 1492,95 ft2
- Total area: 161,8 m2/ 1740,97 ft2
- Net area: 115,1 m2 + garage/ 1238,48 ft2 + garage
-
Usable area:
-
107,45 m2 by PN-70/B-02365/ 1156,16 ft2 by PN-70/B-02365
- 115,11 m2 + garage by PN-ISO 9836:1997/ 1238,58 ft2 + garage by PN-ISO 9836:1997
-
- Roof area: 192,4 m2/ 2070,22 ft2
- Roof slope: 30 degrees
- Height of the building: 6,01 m (6,31 m with foundation)/ 19,71 ft (20,70 ft with founadtion)
- Wide of the building: 16,83 m / 55,20 ft
- Length of the building: 8,34 m / 27,35 ft
- Minimum plot width: 23,83 m / 78,16 ft
- Minimum plot length: 16,21 m / 53,17 ft
- Height of rooms: 2,61 m / 8,56 ft
Materials:
• Foundations - Concrete benches, walls of concrete blocks
• External walls - bilayer of ceramic MAX blocks + polystyrene
• Internal walls – ricks
• Ceiling - Teriva
• Elevation - thin-layer plaster
• Roof - tile
The costs of implementing:
| The raw state open | 34 600,00 EUR |
| The raw state closed | 52 600,00 EUR |
| The cost of finishing works | 43 100,00 EUR |
| Execution of turnkey home | 95 700,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Dominik 2 - detailed file
House plan Dominik 2 - detailed file - mirror
