Favorite house plan is a villa with a compact body, referring to the traditional architecture of the Polish mansion. It is designed for a family of 5 people. On the ground floor an extra room is designed - to work, guest room and a spacious living room with dining room open to a large arcade. In this house plan every room in the attic is equipped with a wardrobe or closet. The room above the garage can be used as a "hobby" room or storeroom - attic. In this house plan is possible to extend the garage. We also have the Favorite house plan in a mirror version.
Specifications:
- Cubature: 763 m3/ 26941,53 ft3
- Built-up area: 160,38 m2/ 1725,69 ft2
- Total area: 263,15 m2/ 2831,49 ft2
- Net area: 259,10 m2/ 2787,92 ft2
-
Usable area:
- 177,45 m2 by PN-70/B-02365/ 1909,36 ft2 by PN-70/B-02365
- 195,17 m2 + garage 21,00 m2 by PN-ISO 9836:1997/ 2100,03 ft2 + garage 225,96 ft2 by PN-ISO 9836:1997
- Roof area: 244,6 m2/ 2631,90 ft2
- Roof slope: 38 degrees
- Height of the building: 7,87 m (8,27 m with foundation)/ 25,81 ft ( 27,13 ft with foundation)
- Wide of the building: 16,98 m/ 55,69 ft
- Length of the building: 11,15 m/ 36,57 ft
- Minimum plot width: 23,98 m/ 78,65 ft
- Minimum plot length: 19,12 m/ 62,71 ft
- Height of rooms: 2,70 m/ 8,86 ft
Materials:
• Foundations - + benches poured concrete block
• External walls - bilayer: porotherm 25 + 15 wool (or polystyrene) + thin-layer plaster or aerated concrete + polystyrene
• Ceiling - reinforced concrete Teriva
• Elevation - thin-layer plaster
• Roof - metal roofing tile or ceramic tile
The costs of implementing:
| The raw state open | 51 200,00 EUR |
| The raw state closed | 76 000,00 EUR |
| The cost of finishing works | 66 400,00 EUR |
| Execution of turnkey home | 142 300,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Favorite - detailed file
House plan Favorite - detailed file - mirror
