Glow house plan

Usable area: 91.81 m2   /   The cost of the realization: 99 000 EUR
House plan Luna - front visualization
Show mirror image


Glow house plan is a storey family house, built on a rectangular plan, covered by gabled roof, with the garage partly embedded into the body of house. This house plan is designed for a family of four people which will need with time more space for additional rooms thanks to the attic to adapt. Unpretentious modern architecture of one-story house, combines traditional form and modern materials, color and detail. The whole creates a modest, but very sympathetic look. The interior of Glow held at the ground floor, separating it into a living part - a living room, hall and partly open kitchen with pantry, and night part - with three bedrooms and a bathroom, and utility room with a garage and boiler room. In a small space we managed to organize spacious and comfortable accommodation for the household. From hall by stairs we get into the attic, which in a second step could be developed to loft with additional rooms. Glow house plan is the perfect choice for those who appreciate the convenience of an apartment on the ground floor but want to have a "reserve" space for use as an attic. This is grate project for people wanting to build a cheap, economical and energy efficient house. We has also a mirror version of the Glow house plan.

Specifications:
  • Cubature: 625 m3 / 22068,75 ft3
  • Built-up area: 148,48 m2 (with arcades 160,16 m2) / 1597,64 ft2 (with arcades 1723,32 ft2)
  • Total area: 148,48 m2 / 1597,64 ft2
  • Net area: 97,20 m2 + garage / 1045,87 ft2 + garage
  • Usable area: 91,81 m2 / 987,88 ft2
  • Roof area: 223,41 m2 / 2403,89 ft2
  • Roof slope: 30 degrees
  • Height of the building: 6,45 m (6,75 m with foundation) / 21,16 ft (22,14 ft with foundation)
  • Wide of the building: 14,99 m / 49,17 ft
  • Length of the building: 12,23 m / 40,11 ft
  • Minimum plot width: 22,99 m / 75,41 ft
  • Minimum plot length: 21,23 m / 69,63 ft
  • Height of rooms: 2,70 m / 8,86 ft
Materials:
  • Foundations - concrete bench and foundation walls with concrete blocks
  • External walls –  brick walls –porotherm 25 blocks + polystyrene + thin-layer plaster
  • Ceiling -  Teriva
  • Roof - tile
  • Elevation - thin-layer plaster on polystyrene






The costs of implementing:
The raw state open 41 300,00 EUR
The raw state closed 63 000,00 EUR
The cost of finishing works 36 000,00 EUR
Execution of turnkey home 99 000,00 EUR

Net notified costs, do not include VAT



To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.



House plan Luna - detailed file

House plan Luna - detailed file - mirror

Comment
Glow house plan 6444 Polis
2015.11.14 0 Pozytywny komentarz Negatywny komentarz

In the end I found my dream house plan.

Glow house plan 3068 Grzegorz Frątczak
2012.10.01 1 Pozytywny komentarz Negatywny komentarz

Hi all, I see that this house plan is very popular, I also chose this one and I do not regret the cottage is very cool and functional. Regards.

Glow house plan 1830 Śmich Klaudia
2012.03.12 0 Pozytywny komentarz Negatywny komentarz

Hello I have a question, if anyone already put raw state of this house? I would like to assess the size of the house in live before buying the same.
