Malibu house plan

Usable area: 315.88 m2   /   The cost of the realization: 252 500 EUR
House plan Malibu - front visualization
Show mirror image


Malibu house plan is a great suburban mansion for a nice plot. The building impresses the beautiful open house spaces to the garden, and a very representative entrance. This story house, was designed combining three units: a two-storey main body of the building, and two ground-floor with attics - garage and hiding a kitchen and dining area. Input from the chamfered corner through the arcade is a violation of the mold of the typical entrance to the residence. The inspiration for Malibu house were patterns of Mediterranean, Italian or French villa, which distinguishes it from other Polish tradition architecture. Breach of the principle of symmetry body and interior gave freedom in shaping the function of each room. Malibu house as a residence in the southern style is surrounded by terraces, arcades, large glazed, connecting the interior with the surrounding garden. Additional variety are balconies and terraces on each floor. The interior of the house is: one open living area with living room, dining room, beautiful glass conservatory, the elegant lobby and partly open kitchen. In addition, the ground floor room - office, and a garage and technical rooms is planned. On the first floor are four bedrooms with wardrobes and two bathrooms, and laundry room, recreation room above the garage, and separate stairs to the attic above the floor, where you can arrange a large room for example studio, or leave the attic. The building is a large, representative, but it is designed without unnecessary extravagance, with attention to the functionality of each piece of interior. There is also available a mirror version of the Malibu house plan.

Specifications:
  • Cubature: 1310 m3 / 46256,1 ft3
  • Built-up area: 265,76 m2 / 2859,58 ft2
  • Total area: 438,43 m2 / 4717,51 ft2
  • Net area: 336,1 m2 + garage / 3616,44 ft2 + garage
  • Usable area: 315,88 m2 / 3398,87 ft2
  • Roof area: 387,75 m2 + flat roof 31,82 m2 / 4172,19 ft2 + flat roof 342,38 ft2
  • Roof slope: 27 degrees
  • Height of the building: 9,92 m (10,34 m with foundation) / 32,54 ft (33,92 ft with foundation)
  • Wide of the building: 18,16 m / 59,56 ft
  • Length of the building: 24,6 m / 80,69 ft
  • Minimum plot width: 26,16 m / 85,80 ft
  • Minimum plot length: 32,6 m / 106,93 ft
  • Height of rooms: 3,0 i 2,7 m / 9,84 and 8,86 ft
Materials:
  • Foundations - concrete bench and foundation walls with concrete blocks
  • External walls –  brick walls –porotherm 25 blocks + polystyrene + thin-layer plaster
  • Ceiling -  Teriva
  • Roof - tile
  • Elevation - thin-layer plaster on polystyrene






The costs of implementing:
The raw state open 81 100,00 EUR
The raw state closed 125 700,00 EUR
The cost of finishing works 126 900,00 EUR
Execution of turnkey home 252 500,00 EUR

Net notified costs, do not include VAT



To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.



House plan Malibu - detailed file

House plan Malibu - detailed file - mirror

Comment
Malibu house plan 1897 Matti
2012.03.11 1 Pozytywny komentarz Negatywny komentarz

I must admit that the area the house is fantastic and every functional. This is a very shapely and interesting house plan. Despite the small area this house has a number of functions and is very nice. I have just order this house plan.

Malibu house plan 1899 Kajtek
2012.03.02 0 Pozytywny komentarz Negatywny komentarz

This house is terrific. More than six months we were looking for a home that would meet while in 80% our expectations, this project turned out to be the fulfillment of our needs in 100%, we cannot believe it :)

Malibu house plan 502 EDzia
2012.02.08 0 Pozytywny komentarz Negatywny komentarz

I'll also build this house, in my case decided minimalism: simple and easy to build solid of curiously designed interior.
