By using this website you consent to the use of cookies, according to the current browser settings.Michael house plan
Usable area: 102.15 m2 / The cost of the realization: 84 000 EUR
Show mirror image
Price: 940 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Realizations (6) Detailed drawings
List of materials
Comments (4)
Michael is a lovely detached house - implemented as a "little brother" of the "Michalina" house plan - both houses are similar in size and layout of the interior, varying the shape of the roof. Michael was designed as a comfortable house for a family of four people - this is one floor building with the usable attic. The ground floor provides living area, with a living room, a dining room, a nice open kitchen hall and a large boiler room. On the top floor are three bedrooms and a comfortable bathroom. The traditional shape of the building, constructed on a square plan, has been covered by a gable roof with dormers. Front elevation varies the roof over the entrance, supported by a column and strut. Garden elevation decorate: dormer with a balcony and a roofing of the terrace supported by columns. The architecture of the house is quiet, at the same time retain the correct proportions of body. Used modern materials and interesting colors give a good effect of entirety. Michael is an excellent option for investors looking for a small, comfortable house for his family, taking into account cost savings, simplicity of construction and low cost of house maintenance. There is also a mirror version of Michael house.
Specifications:
- Cubature: 442 m3 / 15607,02 ft3
- Built-up area: 79,50 m2 / 855,42 ft2
- Total area: 142,42 m2 / 1532,44 ft2
- Net area: 108,96 m2 / 1172,41 ft2
- Usable area: 102,15 m2 / 1099,13 ft2
- Roof area: 150,10 m2 / 1615,08 ft2
- Roof slope: 42 degrees
- Height of the building: 8,23 m (8,53 m with foundation) / 26,99 ft (27,98 ft with foundation)
- Wide of the building: 9,36 m / 30,70 ft
- Length of the building: 8,86 m / 29,06 ft
- Minimum plot width: 16,41 m / 53,82 ft
- Minimum plot length 16,90 m / 55,43 ft
- Height of rooms: 2,60 m / 8,53 ft
Materials:
- Foundations - concrete bench and foundation walls with concrete blocks
- External walls – brick walls –porotherm 25 blocks + polystyrene + thin-layer plaster
- Ceiling - Teriva
- Roof - tile
- Elevation - thin-layer plaster on polystyrene
The costs of implementing:
| The raw state open | 30 000,00 EUR |
| The raw state closed | 42 800,00 EUR |
| The cost of finishing works | 41 200,00 EUR |
| Execution of turnkey home | 84 000,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Michael - detailed file
House plan Michael - detailed file - mirror
