By using this website you consent to the use of cookies, according to the current browser settings.Economical house plan
Economical house plan is a small single-family house, for people who like modern solutions and do not like roofs with eaves. Attic in the project has so high jamb wall that there are almost no slant. This allows fully utilized the attic. House was designed on the plan close to a square. Attic is covered by a gable, symmetrical roof. To the main body was built another garage. House can be set in different ways on the plot - the entrance door to the road, or garage door to enter the plot. Simple, modern body, symmetrically and proportionally placed windows - all these makes the house well fit in every neighborhood. Modern materials and interesting colors of the building, go along with energy efficiency and simple design. On the ground floor there is a daily space, with living room, hall and kitchen, with nicely exposed staircase and fireplace. In the attic there are three bedrooms with a bathroom. On the ground floor there is also built another large boiler room and a garage. Of course you can also build a house without a garage. Thanks to its compact body and a very good isolation, Economical house is energy efficient. Is very easy to adapt to the NF40 standard. Construction is very simple, and allow for a quick and inexpensive building, and subsequent economical exploitations. Small surface of house allows to qualify the project MDM program requirements.
- Cubature: 456 m3 / 16101,36 ft3
-
Built-up area:
- without arcades 92,72 m2 / 997,67 ft2
- with arcades 92,72 m2 / 997,67 ft2
- Total area: 154,72 m2 / 1664,79 ft2
- Net area: 92,52 m2 + garage 20,23 m2 / 995,52 ft2 + garage 217,67 ft2
-
Usable area:
- 87,18 m2 wg PN-70/B-02365 / 938,06 ft2 wg PN-70/B-02365
- 92,52 m2 + garage wg PN-ISO 9836:1997 / 995,52 ft2 + garage wg PN-ISO 9836:1997
- Roof area: 97,08 m2 + flat roof 27,49 m2 / 1044,58 ft2 + flat roof 295,79 ft2
- Roof slope: 45 degrees
- Height of the building: 8,99 m (9,14 m with foundation) / 29,49 ft (29,98 ft with foundation)
- Wide of the building: 12,13 m / 39,79 ft
- Length of the building: 11,93 m / 39,13 ft
- Minimum plot width: 19,13 m / 62,75 ft
- Minimum plot length: 18,93 m / 62,09 ft
- Height of rooms: 2,7 i 2,5 m / 8,86 and 8,2 ft
- Foundations - concrete bench and foundation walls with concrete blocks
- External walls – brick walls –porotherm 25 blocks + polystyrene + thin-layer plaster
- Ceiling - monolithic reinforced concrete
- Elewacje - tynk cienkowarstwowy na styropianie
- Roof - ceramic tile
The raw state open | 28 400,00 EUR |
The raw state closed | 48 000,00 EUR |
The cost of finishing works | 40 600,00 EUR |
Execution of turnkey home | 88 500,00 EUR |
Net notified costs, do not include VAT
