Usable area: 199.79 m2 / The cost of the realization: 163 600 EUR
Show mirror image
Price: 1070 EUR
Description
Plans
Elevations
Situations
Variants (0)
Realizations (10) Detailed drawings
List of materials
Comments (3)
House plan under oak tree is a comprehensive storey villa with attic. It is designed for a family of 4 to 5 people. The building structure was covered with a hipped roof with large dormers on each elevation it makes the house look attractive from all sides. External appearance is diversified by bay windows, and balcony and a garden arcade. Front of the building will appeal to customers who appreciate traditional architecture, but not necessarily wanting to have columns at the entrance to his home. The interior of the ground floor is the combined area of the hall, living room, dining room and kitchen, and an additional room. In the attic are designed four rooms and an attic over the garage that you can freely use. There is also available mirror version of this house plan.
Specifications:
- Cubature: 984 m3 / 34745,04 ft3
- Built-up area: 194,22 m2 / 2089,81 ft2
- Total area: 338,1 m2 / 3637,96 ft2
- Net area: 209,12 m2 + garage + attic / 2250,13 ft2 + garage + attic
- Usable area: 199,79 m2 / 2149,74 ft2
- Roof area: 357,5 m2 / 3846,70 ft2
- Roof slope: 36 and 38 degrees
- Height of the building: 8,24 m (8,64 m with foundation) / 27,03 ft (28,34 ft with foundation)
- Wide of the building: 20,2 m / 66,26 ft
- Length of the building: 12,68 m / 41,59 ft
- Minimum plot width: 27,84 m / 91,32 ft
- Minimum plot length: 20,68 m / 67,83 ft
- Height of rooms: 2,85 m / 9,35 ft
Materials:
- Foundations - concrete bench and foundation walls with concrete blocks
- External walls - bilayer wall porotherm blocks
- Ceiling - Teriva
- Roof - tile
- Elevation - thin-layer plaster
The costs of implementing:
| The raw state open | 57 800,00 EUR |
| The raw state closed | 87 100,00 EUR |
| The cost of finishing works | 76 600,00 EUR |
| Execution of turnkey home | 163 600,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Under the oaks - detailed file
House plan Under the oaks - detailed file - mirror
