Veronika house plan

Usable area: 174.64 m2   /   The cost of the realization: 138 400 EUR
House plan Veronika - front visualization
Show mirror image


Veronica house plan is a charming detached house for a family of four-five people, it is a bungalow with attic, built on a rectangular plan, covered with a hipped roof. The project is dedicated to investors having a fairly narrow plot and wanting to build a shapely, nice house. Calm architecture of Veronica house combines traditional form with contemporary details and modern materials and colors. Front of the house is decorated by a large symmetrical dormer with balcony which at the same time is roof for platform entrance. Entrance is accented by arcade finished with clinker. Garden elevation is decorated with similar dormer with balcony, bay window and dining annex, arcade of living room covering part of the terrace. Veronica interior is divided into a living area and technical rooms on the ground floor, and bedrooms in the attic. Downstairs, is a very nice interior, with elegant lobby and representative staircase, a living room with interestingly designed dining area overlooking the garden and kitchen open to the living room. Near the entrance there is extra room - office or extra bedroom. On the ground floor there are also: a built-in block garage, and a boiler room. In the attic are designed four bedrooms, a large shared bathroom and a dressing room accessible from the hall. You can easily convert garden bedrooms for parents’ apartment with a separate bathroom and dressing room - if needed. Above the attic there is a large, very useful attic. Veronica house plan is a building of simple design, inexpensive to implement and energy efficient. This house fits on a narrow plots. There is also available mirror version of this house plan.

Specifications:
  • Cubature: 858 m3 / 30295,98 ft3
  • Built-up area: 137,06 m2 (143,56 m2) / 1474,77ft2 (1544,71 ft2)
  • Total area: 246,58 m2 / 2653,20 ft2
  • Net area: 181,14 m2 + garage / 1949,07 ft2 + garage
  • Usable area: 174,64 m2 / 1879,13 ft2
  • Roof area: 246,92 m2 / 2656,86 ft2
  • Roof slope: 42 degrees
  • Height of the building: 8,79 m (8,99 m with foundation) / 28,83 ft (29,49 ft with foundation)
  • Wide of the building: 9,80 m / 32,14 ft
  • Length of the building: 15,30 m / 50,18 ft
  • Minimum plot width: 17,80 m / 58,38 ft
  • Minimum plot length: 23,3 m / 76,42 ft
  • Height of rooms: 2,67 m / 8,76 ft
Materials:
  • Foundations - concrete bench and foundation walls with concrete blocks
  • External walls –  brick walls –porotherm 25 blocks + polystyrene + thin-layer plaster
  • Ceiling -  Teriva
  • Roof -  tile
  • Elevation - thin-layer plaster on polystyrene






The costs of implementing:
The raw state open 49 100,00 EUR
The raw state closed 73 800,00 EUR
The cost of finishing works 64 600,00 EUR
Execution of turnkey home 138 400,00 EUR

Net notified costs, do not include VAT



To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.



House plan Veronika - detailed file

House plan Veronika - detailed file - mirror
