Sonnet house plan

Usable area: 189.43 m² / The cost of the realization: 179 000 EUR

Show mirror image

Price: 1110 EUR

Description Plans Elevations Situations Animation Variants (0) Realizations (7) Detailed drawings List of materials Comments (3)

Sonnet is elegant storey villa, with a shape of rectangular block, with the garage with a cut from the side and covered by small roof. The division of the elevation into horizontal stripes visually lowers the building, which seems to be closer to human scale. Arcades - entrance and garden, dining room, bay window, round window in the front elevation - add variety to the silhouette of the house. Sonnet interior is designed in such way to divide villa in the living space on the ground floor and night on the first floor. On the ground floor an extra room with bathroom, garage and boiler room was also designed. House despite the small size is very roomy and functional, has many rooms and auxiliary rooms. There is also a mirror version of the Sonnet house plan.

Specifications:

Cubature: 895 m³ / 31602,45 ft³
Built-up area: 197 m² / 2119,72 ft²
Total area: 329,05 m² / 3540,58 ft²
Net area: 223,07 m²+ garage / 2400,23 ft² + garage
Usable area: 189,43 m² / 2038,27 ft²
Roof area: 315,12 m² / 3390,69 ft²
Roof slope: 25 and 30 degrees
Height of the building: 8,98 m (9,33 m with foundation) /29,45 ft (30,60 ft with foundation)
Wide of the building: 13,86 m / 45,46 ft
Length of the building: 16,54 m / 54,25 ft
Minimum plot width: 20,86 m / 68,42 ft
Minimum plot length: 24,54 m / 80,49 ft
Height of rooms: 2,8 m / 9,18 ft

Materials:

Foundations - concrete bench and foundation walls with concrete blocks
External walls – bilayer walls –porotherm blocks + polystyrene
Internal walls - porotherm
Ceiling - Teriva
Roof - tile
Elevation - thin-layer plaster

The costs of implementing:

The raw state open	62 800,00 EUR
The raw state closed	90 900,00 EUR
The cost of finishing works	88 200,00 EUR
Execution of turnkey home	179 000,00 EUR

Net notified costs, do not include VAT

Order

Additions to the project:

Energy-saving package free

Ventilation and fireplace package 90,00 EUR

Central vacuum package 70,00 EUR

The electronic version of the project 120,00 EUR

Solar installation package 70,00 EUR

Underfloor heating package 80,00 EUR

Heat pump package 70,00 EUR

Water jacket package 70,00 EUR

Boiler for solid fuel package 80,00 EUR

Air conditioning package 80,00 EUR

Fencing projects 140,00 EUR

Septic tanks sealed package free

Projekt domu Sonet - zestawienie materiałowe

To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.

House plan Sonnet - detailed file

House plan Sonnet - detailed file - mirror
