Usable area: 226.5 m2 / The cost of the realization: 185 800 EUR
Show mirror image
Price: 1210 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Realizations (44) Detailed drawings
List of materials
Comments (3)
Sweet house plan is a charming, two-story house for a family of 4-6 people. The building was constructed by combining storey residential part of the ground floor and the attic of built another garage. In this house roofs, balconies, terraces and pergolas are a variety economical of body. The division of the garage walls of the house on two horizontal stripes visually lowers storey house silhouette. The interior of house is a single-space ground floor, with living room, dining room and hall. On the first floor was designed bedrooms. On the ground floor we managed to save an extra room that could serve as an office or extra bedroom. On the ground floor there is also a garage and technical rooms. On the floor above the garage it resulted in a large space for any design. Especially charming in this project is roofed terrace with large glass of the dining room and living room - it is a smooth transition between the interior and the garden. There is also available mirror version of this house plan.
Specifications:
- Cubature: 990 m3 / 34956,9 ft3
- Built-up area: 205,71 m2 / 2213,44 ft2
- Total area: 361,87 m2 / 3893,72 ft
- Net area: 243,76 m2 + garage 37,26 m2 / 2622,86 ft2 + garage 400,92 ft2
- Usable area: 226,50 m2 / 2437,14 ft2
- Roof area: 346 m2 / 3722,96 ft2
- Roof slope: 2 and 35 degrees
- Height of the building: 9,48 m (9,98 m with foundation) / 31,09 ft (32,73 ft with foundation)
- Wide of the building: 17,22 m / 56,48 ft
- Length of the building: 14,53 m / 47,66 ft
- Minimum plot width: 25,27 m / 82,89 ft
- Minimum plot length: 22,53 m / 73,90 ft
- Height of rooms: 2,75 i 2,70 m / 9,02 and 8,86 ft
Materials:
- Foundations - concrete bench and foundation walls with concrete blocks
- External walls - bilayer: blocks silicate + mineral wool
- Ceiling - Teriva/wood
- Roof - tile
- Elevation - thin-layer plaster
The costs of implementing:
| The raw state open | 67 900,00 EUR |
| The raw state closed | 98 100,00 EUR |
| The cost of finishing works | 87 700,00 EUR |
| Execution of turnkey home | 185 800,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Sweet - detailed file
House plan Sweet - detailed file - mirror
