Peaceful house plan

Usable area: 101.78 m2   /   The cost of the realization: 99 900 EUR
House plan Peaceful - front visualization
Show mirror image


Peaceful house plan is a detached house for a family of 4-5 people with attic, covered by gable roof, with built another garage. This small house has itself all that you need for comfortable living of each family. Its appearance, traditional style of architecture - creates an aura of solidity. Thanks to its design small building seems to be bigger and more presentable. Access to the house emphasized nice roofed supported by small columns on the side. Its appearance, traditional style of architecture - creates an aura of solidity. Thanks to its design small building seems to be bigger and more presentable. Access to the house emphasized nice roofed supported by small columns on the side. Its appearance, traditional style of architecture - creates an aura of solidity . Thanks to its design small building seems to be bigger and more presentable. Access to the house emphasized nice roofed supported by small columns on the side. Wide glass doors with side light invite inside. Peaceful front façade is decorated with corner windows and dormer in the roof located symmetrically above the entrance. From the garden we have a beautiful wide balcony doors, from which you can go straight from the living room to partially roofed terrace. Interior of the house was divided into day part with bedroom, and utility part. On the ground floor connected living room, hall and open kitchen create a living space. A bit on the side there is an additional room that can be a bedroom or office, bathroom and stairs to the attic. From the lobby we enter also  to boiler room and the garage. In the attic there are three comfortable bedrooms with fitted wardrobes, and a bathroom. In this two bedrooms, wardrobes can be converted into small dressing rooms. House has a simple structure and is easy and inexpensive to build. Thanks to compactness of the solid, energy-efficient solutions and a small cubic capacity, house will be inexpensive to maintain later. There is also available mirror version of this house plan.

Specifications:
  • Cubature: 527 m3 / 18608,37 ft3
  • Built-up area: 100,47 m2 (with arcades: 111,8 m2) / 1081,06 ft2 (with arcades: 1202,97 ft2)
  • Total area: 163,4 m/ 1758,18 ft2
  • Net area: 105,89 m2 + garage 18,60 m2 / 1139,38 ft2 + garage 200,14 ft2
  • Usable area:
    • 101,78 m2 wg PN-70/B-02365 /1095,15 ft2 wg PN-70/B-0236
    • 105,89 m2 + garage wg PN-ISO 9836:1997 / 1139,38 ft2 + garage wg PN-ISO 9836:1997
  • Roof area: 185,61 m2 / 1997,16 ft2
  • Roof slope: 42 degrees
  • Wysokość budynku: 8,13 m (8,44 mwith foundation) / 26,67 ft (27,68 ft with foundation)
  • Wide of the building: 12,55 m / 41,16 ft
  • Length of the building: 8,50 m / 27,88 ft
  • Minimum plot width: 19,55 m / 64,12 ft
  • Minimum plot length: 17,2 m / 56,42 ft
  • Height of rooms: 2,6 i 2,5 m / 8,53 and 8,2  ft
Materials:
  • Foundations - concrete bench and foundation walls with concrete blocks
  • External walls –  brick walls –porotherm 25 blocks + polystyrene + thin-layer plaster
  • Ceiling - Teriva
  • Roof - ceramic tile
  • Elevation - thin-layer plaster on polystyrene






The costs of implementing:
The raw state open 37 400,00 EUR
The raw state closed 52 900,00 EUR
The cost of finishing works 47 100,00 EUR
Execution of turnkey home 99 900,00 EUR

Net notified costs, do not include VAT



To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.



House plan Peaceful - detailed file

House plan Peaceful - detailed file - mirror

Comment
Peaceful house plan 4509 Ewa i Błażej_
2013.10.07 0 Pozytywny komentarz Negatywny komentarz

I wonder about the purchase this project, but I want to set up solar panels, whether it is possible in this house?

MG Projekt answer
Hello. In this house you can easily install the solar system - you can buy it from us as the addition to the basic version the package of solar installation. MG
Peaceful house plan 4503 Igor_
2013.10.01 0 Pozytywny komentarz Negatywny komentarz

Hi all, I see that this hause plan is very popular, I also chose this one and I do not regret the cottage is very cool and functional. Regards.

Peaceful house plan 4506 Janek@
2013.09.28 0 Pozytywny komentarz Negatywny komentarz

Hello I have a question, if anyone already put raw state of this house? I would like to assess the size of the house in live before buying the same.
