Usable area: 132.52 m2 / The cost of the realization: 131 300 EUR
Show mirror image
Price: 1040 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Realizations (4) Detailed drawings
List of materials
Comments (3)
Cameral house plan is a charming one-story house with an attic for a family of four to five people. Main rectangular body of the building is covered with a hipped roof, it is also built in the garage. Architecturally the house loosely refers to the tradition of Polish manor house. The roof was varied by large dormer windows, in front elevation centrally designed arched dormer window is supported by two columns and creating at the same time an arcade entrance. From the garden elevation two symmetrically placed dormers dominate above the comfortable roof of the terrace. Dormer combined with a bay window in the dining room ended by a balcony in the side elevation completes the whole composition. The interior of Cameral house is divided into a living and business on the ground floor and bedrooms on the attic. On the ground floor there is a spacious living room, connected in part with a large kitchen and hall. It is also provides an extra room for example a study or a guest bedroom, and bathroom and boiler room. In the garage there is an extra storage room. On the attic there are three easy to arrange bedrooms, two dressing rooms and a very nice bathroom. Additionally, you can adapt an attic above the garage for an extra room. There is also available a mirror version of this house plan.
Specifications:
- Cubature: 753 m3 / 26588,43 ft3
- Built-up area: 137,87 m2 / 1483,48 ft2
- Total area: 230,35 m2 / 2478,57 ft2
- Net area: 154,00 m2 + garage / 1657,04 ft2 + garage
- Usable area: 132,52 m2 / 1425,92 ft2
- Roof area: 244,01 m2 / 2625,55 ft2
- Roof slope: 40 and 45 degrees
- Height of the building: 8,18 m (8,48 m with foundation) / 26,83 ft (27,81 ft with foundation)
- Wide of the building: 15,23 m / 49,95 ft
- Length of the building: 10,02 m / 32,87 ft
- Minimum plot width: 22,33 m / 73,24 ft
- Minimum plot length: 19,47 m / 63,86 ft
- Height of rooms: 2,67 m / 8,76 ft
Materials:
Foundations - concrete benches and foundation walls with concrete blocks
Exterior walls - brick walls - airbricks porotherm 25 + polystyrene + plaster thin
Ceiling – TERIVA
Elevation - thin-layer plaster on polystyrene
Roof – tile
The costs of implementing:
| The raw state open | 51 900,00 EUR |
| The raw state closed | 76 600,00 EUR |
| The cost of finishing works | 54 800,00 EUR |
| Execution of turnkey home | 131 300,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Cameral - detailed file
House plan Cameral - detailed file - mirror
