Usable area: 112.1 m2 / The cost of the realization: 116 200 EUR
Show mirror image
Price: 970 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Realizations (7) Detailed drawings
List of materials
Comments (3)
Natty with dormers is suitable for a family of four-five. It is a variant version of the Natty house plan. A simple gable roof is varied by large dormers on the front and back of the house. On the ground floor house apart from addition living room an extra room and bathroom was designed. On the attic there are three bedrooms, a large bathroom and loft above the garage. This house plan is characterized by a representative architecture and functional interiors. There is also available a version of this house plan.
Specifications:
- Cubature: 516 m3 / 18219,96 ft3
- Built-up area: 118,73 m2 / 1277,53 ft2
- Total area: 167,94 m2 / 1807,03 ft2
- Net area: 135,68 m2 / 1459,92 ft2
- Usable area: 112,1 m2 / 1206,20 ft2
- Roof area: 206,7 m2 / 2224,09 ft2
- Roof slope: 38 degrees
- Height of the building: 7,20 m (7,60 m with foundation) / 23,62 ft (24,93 m with foundation)
- Wide of the building: 14,11 m / 46,28 ft
- Length of the building: 9,18 m / 30,11 ft
- Minimum plot width: 22,11 m / 72,52 ft
- Minimum plot length: 17,18 m / 56,35 ft
- Height of rooms: 2,68 m / 8,79 ft
Materials:
- Foundations – poured concrete
- External walls - aerated concrete 24 cm + foamed polystyrene 12 cm
- Ceiling - Reinforced concrete Teriva
- Elevation - thin-layer acrylic plaster
- Roof - tile or meatal roofing tile
The costs of implementing:
| The raw state open | 37 500,00 EUR |
| The raw state closed | 55 400,00 EUR |
| The cost of finishing works | 60 800,00 EUR |
| Execution of turnkey home | 116 200,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Natty with dormers - detailed file
House plan Natty with dormers - detailed file - mirror
