Usable area: 170.22 m2 / The cost of the realization: 131 400 EUR
Show mirror image
Price: 1000 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Realizations (15) Detailed drawings
List of materials
Comments (3)
Natty 4 is a single-family villa for a family of four to five people. It was created as variant version of Natty house plan. It is characterized by an interesting entrance portico on columns and a large window above the entrance. Natty 4 house is a representative architecture and functional interior. Garage has been expanded and obtained an extra space. On the ground floor apart to the living room an extra room and bathroom was designed. At the attic there are four bedrooms and a large bathroom. We have also a mirror version of Natty 4 house plan.
Specifications:
- Cubature: 664 m3 / 23445,84 ft3
- Built-up area: 135,93 m2 / 1462,61 ft2
- Total area: 231,55 m2 / 2491,48 ft2
- Net area: 186,36 m2 / 2005,23 ft2
- Usable area: 170,22 m2 / 1831,57 ft2
- Roof area: 226 m2 / 2431,76 ft2
- Roof slope: 38 degrees
- Height of the building: 7,70 m (8,10 m with foundation) / 25,26 ft (26,57 ft with foundation)
- Wide of the building: 16,11 m / 52,84 ft
- Length of the building: 9,98 m / 32,73 ft
- Minimum plot width: 24,11 m / 79,08 ft
- Minimum plot length: 17,98 m / 58,97 ft
- Height of rooms: 2,68 m / 8,79 ft
Materials:
- Foundations - poured concrete
- External walls - aerated concrete 24 cm + foamed polystyrene 12 cm
- Ceiling - reinforced concrete Teriva
- Elevation - thin-layer acrylic plaster
- Roof - tile or meatal roofing tile
The costs of implementing:
| The raw state open | 43 900,00 EUR |
| The raw state closed | 63 800,00 EUR |
| The cost of finishing works | 67 600,00 EUR |
| Execution of turnkey home | 131 400,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Natty 4 - detailed file
House plan Natty 4 - detailed file - mirror
