House plan House with a view 2 C

Usable area: 245.25 m2   /   The cost of the realization: 224 180 EUR
Projekt domu Dom z widokiem 2 C - wizualizacja frontu
Show mirror image


House with a view 2 C is a project of single-family house with modern architecture, from the collection of popular series "Houses with a view". The building was composed of two main blocks - a two-storey core, covered with an L-shaped roof, and a one-story garage block covered by a three-sided roof. Due to the fairly large roof pitch, there is a large attic above the floor, which can be successfully adapted to the usable attic with additional rooms. The body of the building is decorated with a nice detail. Corner windows, large glazing, stone and wooden wall cladding - all these elements give the facade chic and elegant look. The building has a representative appearance - evokes the impression of comfort and luxury. The interior has been designed with a division into the living and utility space on the ground floor, and bedrooms upstairs. We enter the house with a well-lit vestibule with a cloakroom, immediately to a nice lobby, and then to the living room with emptiness and beautiful representative stairs, and a large kitchen with an island, and a dining room. In the utility part on the ground floor, we have a two-car garage with additional storage space and a separate boiler room. Living room and dining room open with large glazed windows on the wide terrace partially covered with a pergola. From the corner window of the kitchen, we can see the entrance and the entrance to the house. On the first floor, there is parents' apartment with dressing room, bathroom and own terrace available from the bedroom, as well as two children's bedrooms with bathroom. Above the garage we have a large additional attic space that can be used in any way. In the attic above the first floor we have a studio of over 60 sq m, which can also be easily freely adapted. The project is an excellent offer for investors who want a large house, but have limited space or a small plot, and is obligated to build a house with a roof with a higher inclination angle. This house plan will perfectly fit into the plot with a garden on the side, and on the plot with entry to the property from the sunny side - for example from the south. The building uses energy-efficient materials and technologies, so that the house will be inexpensive in later operation.

Specifications:
  • Cubature: 1545 m3 / 54553,95 ft3
  • Built-up area:  220,47 m2 / 2372,26 ft2
  • Total area: 399,07 m2 / 4293,99 ft2
  • Net area: 265,61 m2 + garage 35,10 m2 / 2857,96 ft2 +garage 377,68 ft2
  • Usable area: 245,25 m2 /  2638,89 ft2
  • Dimensions of the house: 23,05 x 14,09 m / 75,60 x 46,22 ft
  • Minimum dimensions of the plot: 30,05 x 22,09 m / 98,56 x 72,46 ft
  • Height of the building: 11,30 m (11,80 with foundation) / 37,06 ft (38,70 ft with foundation)
  • Roof area: 340,50 m2 / 3663,78 ft2
  • Roof slope: 40 degrees
  • Height of rooms: 2,98 i 2,7 m / 9,77 and 8,86 ft
Materials:
  • Foundations - concrete bench and foundation walls with concrete blocks
  • External walls –  brick walls –porotherm 25 blocks + polystyrene + thin-layer plaster
  • Ceiling -  monolithic
  • Elevation - thin-layer plaster on polystyrene
  • Roof -  sheet metal seam (alternatively tile)




The costs of implementing:
The raw state open 89 950,00 EUR
The raw state closed 134 680,00 EUR
The cost of finishing works 89 510,00 EUR
Execution of turnkey home 224 180,00 EUR

Net notified costs, do not include VAT



The project does not yet have the technical drawings.
