Regent house plan

Usable area: 486.57 m2   /   The cost of the realization: 317 700 EUR
House plan Regent - front visualization
Show mirror image


Regent house plan is an elegant, extended residence for the lucky ones with a beautiful plot. Regent has all the necessary functions: representative hall with a beautiful staircase, large dining room and living room, an extensive library and a beautiful kitchen. At the entrance was designed large, comfortable dressing room. On the first floor was planned parents' apartment with bathroom and dressing room, and two additional bedrooms - with private bathroom (alternatively can also be two bathrooms - separately for each room). On the first floor there is also one spare room. In a separate wing of the house is a large garage with utility space. Above the garage in the attic room was designed sport and recreation room accessible from the ground floor separate staircase. Regent house is designed in such a way as to avoid frequent in large houses accumulation of smaller spaces - there is not much room, but they are large. Of course, a house can be freely arranged inside - in accordance with the clients wishes. There is also available mirror version of this house plan.

Specifications:
  • Cubature: 2240 m3 / 79094,4 ft2
  • Built-up area: 390,59 m2 / 4202,75 ft2
  • Total area: 728,65 m2 / 7840,27 ft2
  • Net area: 610,12 m2 with garage / 6564,89 ft2 with garage
  • Usable area: 486,57 m2 / 5235,49 ft2
  • Roof area: 453,76 m2 / 4882,46
  • Roof slope: 30 degrees
  • Height of the building: 9,76 m (10,16 m with foundation) / 32,013 ft (33,32 ft with foundation)
  • Wide of the building: 25,09 m / 82,29 ft
  • Length of the building: 27,08 m / 88,82 ft
  • Minimum plot width: 33,09 m / 108,54 ft
  • Minimum plot lengthi: 37,83 m / 124,08 ft
  • Height of rooms: 3,0 m / 9,84 ft
Materials:
  • Foundations - concrete bench and foundation walls with concrete blocks
  • External walls –  brick walls  porotherm + mineral wool
  • Interior walls - porotherm
  • Ceiling -  monolithic reinforced concrete and teriva
  • Roof - tile
  • Elevation - thin-layer plaster






The costs of implementing:
The raw state open 122 800,00 EUR
The raw state closed 168 500,00 EUR
The cost of finishing works 149 300,00 EUR
Execution of turnkey home 317 700,00 EUR

Net notified costs, do not include VAT



To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.



House plan Regent - detailed file

House plan Regent - detailed file - mirror
