Romeo house plan

Usable area: 161.51 m2   /   The cost of the realization: 155 900 EUR
House plan Romeo - front visualization
Show mirror image


Romeo house plan is a comfortable family house, for a family of four-to six people, with an attic. The building has a compact body, designed on a square plan, with an added part of the garage and utility rooms. It is a variant version of Julka house plan - its bigger brother. Architecturally, house refers to the tradition of pre-war Polish manor house and villas, but in the modern spirit - using modern materials and technology. The house is very well insulated - easily can become energy-efficient building. Front elevation is decorated by entrance platform, over which the two columns support little balcony. Wide doors with side glazing invite us to the interior. Garden elevation is decorated with living room bay window with a beautiful large window, and an arcade through which by the wide patio doors we can go out from the living room to the terrace and garden. The interior of house plan is divided into a living area on the ground floor, part of the night - with a bedroom in the attic, and utility part in the annex garage building d. Beautiful, very large living room, connected to the lobby and half open kitchen create a comfortable, representative living space. In the middle of this space are beautiful stairs to the attic, which adorning the hall. Next to the kitchen is a necessary pantry. On the other side of the atrium you can find an extra room (office or guest bedroom). From the lobby we go to double garage and a large boiler. In the attic there are three comfortable bedrooms and a spacious bathroom. Master bedroom - with its own dressing room. Above the garage is a free space of attic, which can be easily adapted for utility purposes. House plan Romeo is well thought out, functional and comfortable building. There is also available mirror version of this house plan.

Specifications:
  • Cubature: 877 m3 / 30966,87 ft3
  • Built-up area: 170,98 m2 (with arcades: 185,50 m2) / 1839,74 ft2 (with arcades: 1995,98 ft2)
  • Total area: 269,97 m2 / 2904,88 ft2
  • Net area: 171,26 m2 + garage 35,58 m2 + attic / 1842,76 ft2 + garage 382,84 ft2 + attic
  • Usable area:
    • 161,51 m2 wg PN-70/B-02365 / 1737,85 ft2 wg PN-70/B-02365
    • 171,26 m2 + garage wg PN-ISO 9836:1997 / 1842,76  ft2 + garage wg PN-ISO 9836:1997
  • Roof area: 281,04 m2 / 3023,99 ft2
  • Roof slope: 40 degrees
  • Height of the building: 8,78 m (9,03 m with foundation) / 28,80 ft (29,62 ft with foundation)
  • Wide of the building: 17,71 m / 58,09 ft
  • Length of the building: 11,91 m / 39,06 ft
  • Minimum plot width: 25,38 m / 83,25 ft
  • Minimum plot length: 20,06 m / 65,80 ft
  • Height of rooms: 2,7 i 2,5 m / 8,86 ft and 8,2 ft
Materials:
  • Foundations - concrete bench and foundation walls with concrete blocks
  • External walls –  brick walls –porotherm 25 blocks + polystyrene + thin-layer plaster
  • Ceiling -  Teriva
  • Roof - ceramic tile
  • Elevation - thin-layer plaster on polystyrene






The costs of implementing:
The raw state open 60 000,00 EUR
The raw state closed 86 500,00 EUR
The cost of finishing works 69 500,00 EUR
Execution of turnkey home 155 900,00 EUR

Net notified costs, do not include VAT



To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.



House plan Romeo - detailed file

House plan Romeo - detailed file - mirror
